How Did Polygons Form on Pluto?

“Evidence suggests this could be a roiling sea of volatile nitrogen ice,” Melosh said. “Imagine oatmeal boiling on the stove; it doesn’t produce one bubble for the entire pot as the heated oatmeal rises to the surface and the cooler oatmeal is pushed down into the depths, this happens in small sections across the pot, creating a quilted pattern on the surface similar to what we see on Pluto. Of course, on Pluto this is not a fast process; the overturn within each unit happens at a rate of maybe 2 centimeters per year.”

The surface of Pluto appears to be primarily very cold water ice. However, within the Sputnik Planum region the icy surface drops into a basin that holds a pool of nitrogen ice. Both water and nitrogen are solids at Pluto’s temperatures, but the nitrogen ice is structurally weak and has a low viscosity that allows it to deform and flow like a fluid, while the water ice has a very high viscosity and can form tall, hard mountains, Trowbridge said.

“Within this pool of nitrogen ice, there are mountains of water ice that have collected at the edges of the polygons,” he said. “The way they have collected suggests they have moved or floated like icebergs with the convection current. If this is true, we can calculate how deep the pool would need to be for the icebergs to float freely without catching on the bottom.”

The polygons also can provide information about the depth of the pool of nitrogen through known ratios of width to depth for individual cells of convection, he said.

Data show the polygons are 20 to 30 kilometers in diameter. Only the tips of the water icebergs can be seen, and the team performed calculations as if they were spheres, a regular shape that requires the shallowest volume of liquid to float, to create conservative depth estimates, Trowbridge said.

The team’s calculations based on the water icebergs suggest the pool must be at least 5 kilometers deep, and the calculations based on the width-to-depth ratio of the nitrogen convection cells suggest it is 10 kilometers deep. The results of both calculations suggest a far deeper layer of nitrogen ice than the minimum 500 meters needed for convection to occur, he said.

Overturn from convection would erase impact craters and renew this section of the dwarf planet’s surface, which fits with the data New Horizons provided. From this data the surface of Pluto’s Sputnik Planum is estimated to be less than 10 million years old, which is considered very young and suggests significant activity on the surface. However, the Purdue team’s convection model suggests that the age of the surface of the nitrogen ice fields of the Sputnik Planum region is even younger, around one million years old, he said.

“Many people expected Pluto to be a cold, dead world,” Melosh said. “What we’ve discovered through this mission is that cold worlds like Pluto have a different kind of activity that involves materials we think of as gases. This understanding offers a new perspective that cold worlds can be just as active and interesting as our own.”

In addition to Trowbridge and Melosh, the research team includes Jordan Steckloff, who was a graduate student at Purdue the time of the research, and Andy Freed, a Purdue professor of earth, atmospheric and planetary sciences.
